Basic Information
|
|||
|
Announcement model:
|
ZZ3257V434GF1
|
Drive form:
|
6X4
|
|
Wheelbase:
|
4325+1350mm
|
engine:
|
Weichai WP10H400E62
|
|
Gearbox:
|
SINOTRUK HW19712CL
|
Rear axle speed ratio:
|
5.92
|
|
Body length:
|
9.32 meters
|
Body width:
|
2.55 meters
|
|
Body height:
|
3.45 meters
|
Front track:
|
2022mm
|
|
Rear wheelbase:
|
1860/1860mm
|
Vehicle weight:
|
12.5 tons
|
|
Rated load:
|
12.37 tons
|
Total mass:
|
25 tons
|
|
Tonnage level:
|
Heavy Truck
|
Approach angle:
|
17 degrees
|
|
Departure angle:
|
32 degrees
|
Origin:
|
Shandong Jinan
|
|
Market segments:
|
Urban construction debris
|
Version:
|
Standard weight
|
|
Fuel type:
|
diesel fuel
|
||
|
Engine parameters
|
|||
|
engine model:
|
Weichai WP10H400E62
|
Engine brand:
|
Weichai
|
|
Number of cylinders:
|
6 cylinder
|
Fuel type:
|
diesel fuel
|
|
Displacement:
|
9.5L
|
Emission Standards:
|
National VI
|
|
Maximum horsepower:
|
400 HP
|
Maximum output power:
|
294kW
|
|
Maximum torque:
|
1900N路m
|
Maximum torque speed:
|
1200-1300rpm
|
|
Rated speed:
|
1900rpm
|
Engine form:
|
In-line, direct injection, water cooling, four-stroke, supercharged intercooling, electronically controlled high-pressure common
rail, Hi+SCR |
|
Carton parameters
|
|||
|
Carton length:
|
6.3 meters
|
Cargo box width:
|
2.35 meters
|
|
Cargo box height:
|
1.5 m
|
Container form:
|
Self-unloading
|
|
Gearbox parameters
|
|||
|
Gearbox model:
|
SINOTRUK HW19712CL
|
Gearbox brand:
|
SINOTRUK
|
|
Forward gear:
|
12 gears
|
Number of reverse gears:
|
2
|
|
Tank
|
|||
|
Fuel tank capacity:
|
400L
|
||
|
Chassis parameters
|
|||
|
Frame size:
|
300mm
|
Front axle description:
|
7.5T
|
|
Allowable load on front axle:
|
7000kg
|
Rear axle description:
|
16T engineering double-stage bridge
|
|
Allowable load on rear axle:
|
18000(two-axle group)kg
|
Speed atio:
|
5.92
|
|
Number of spring leaves:
|
11/12
|
||
|
Tire
|
|||
|
Tire specifications:
|
12.00R20 16PR
|
Number of tires:
|
10
|
