| Basic Information | |||
| Driving license: | A2 | Announcement Model: | ZZ4187V391KF1 |
| Drive type: | 4X2 | Wheelbase: | 3900mm |
| engine: | Sinotruk MC13H.51-61 | Gearbox: | Sinotruk HW25716XAL |
| Rear axle ratio: | 3.08 | Body length: | 6.39 m |
| Body width: | 2.53 m | Ride height: | 3.82 m |
| Front track: | 2022mm | Rear track: | 1830mm |
| Vehicle weight: | 6.8 tons | Total mass: | 18 tons |
| Total traction mass: | 35 tons | Maximum speed: | 89km/h |
| Origin: | Jining | Tonnage level: | Heavy Truck |
| Fuel Type: | diesel fuel | ||
| Engine parameters | |||
| Engine Model: | Sinotruk MC13H.51-61 | Engine Brand: | Sinotruk |
| Number of cylinders: | 6 cylinders | Fuel Type: | diesel fuel |
| Cylinder arrangement: | In-line | Displacement: | 13.02L |
| Emission standards: | National VI | Maximum horsepower: | 510 hp |
| Maximum output power: | 378kW | Maximum Torque: | 2400N m |
| Maximum torque speed: | 950-1400rpm | Rated speed: | 1800rpm |
| Cab parameters | |||
| Number of passengers allowed: | 2 people | Number of Seat Rows: | Half row |
| Gearbox parameters | |||
| Gearbox Model: | Sinotruk HW25716XAL | Gearbox brand: | Sinotruk |
| Shifting method: | AMT | Forward gears: | 16 levels |
| Reverse gear number: | 2 | ||
| tank | |||
| Fuel tank capacity: | 1000L | ||
| Chassis parameters | |||
| Permissible load on front axle: | 6500kg | Permissible load on rear axle: | 11500kg |
| Speed atio: | 3.08 | Number of springs: | 2/- |
| tire | |||
| Number of tires: | 6 | Tire specifications: | 12R22.5 18PR |
