The Howo 371 truck tractor Trailer uses a 371HP engine. This Howo 371 truck tractor have good passability, low noise, low fuel consumption and high work efficiency.
The cab is comfortable and spacious with an ergonomic design and the driver can relieve fatigue during driving. This Howo 371 truck tractor is very competitive in Africa, affordable, high quality and very popular.
| Engine: | Wheels&Tyres: | ||
| Engine model: | D12.42-20, Euro II emission standard, 4 stroke injection diesel engine, 6 cylinders in-line with water cooling, turbo-charging & inter cooling, mechanical high-pressure oil pump system | Rims: | 8.5-20,10 hole-steel |
| Maximum output: | 371PS (309kW) at 2000 rpm | Types: | 12.00R20 Option:12R22.4,12.00-24,12.00-20,13R22.5, 315/80R22.5, 295/80R22.5, 11.00R20 |
| Maximum torque: | 1820Nm at 1100-1400rpm | Driver'sCab: | Long cab, all-steel forward control, 55°hydraulic tilting to the front, 2-arm windscreen wiper system with 3 speeds, VDO electrical control system, laminate windscreen, with casted-in radio aerial, adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, with stereo radio/cassette recorder, sun visor, safety belt, air conditioner, 2 warming light |
| Bore: | 126mm | Dimensions inmm: | |
| Stroke: | 155mm | Wheel base (mm): | 3200+1350 |
| Displacement: | 11.596L | Front wheel track (mm): | 2022/2041 |
| Clutch: | SINOTRUK’s 430C diaphragm spring clutch, hydraulically operating with air assistance | Rear wheel track (mm): | 1830/1830 |
| Transmission: | Overhang(front/rear) (mm): | 1500/725 | |
| Transmission, model HW19710, 10 forward and 2 reverse | Approach angle(°) | 16 | |
| Ratio: | 4.42 4.8 5.73 | Departure angle(°): | 70 |
| Front Axle: | New HF9 series, with drum brake system | Overall Dimension (mm) | 6800x2496x2958 |
| Rear Axle: | HC16 pressed axle housing, single reduction and differential locks between axles; with drum brake system. | Weight in kg: | |
| Steering: | ZF8118, hydraulic steering with power assistance | Rated loading capacity at fifth wheel (kg): | 15660 |
| Ratio: | 22.2-26.2:1 | Dead weight (kg) | 9210 |
| Gross vehicle weight (kg) | 25000 | Gross combination weight（kg） | 7000 |
| Front axle loading capacity (kg): | 9000 | Rear axle loading capacity (kg) | 2*16000 |
| Performance Maximum driving speed(km/h) | 102(reference data) | Maximum gradeability (%): | 33 |
| Minimum ground clearance(mm) | 265 | Minimum turning radius (m): | 18.5 |
| Fuel consumption(L/100km) |
40(reference data) |
||
