3 Axles Cargo Side Wall Semi Trailer

3 Axles Cargo Side Wall Semi Trailer

Sidewall Semi Trailer.

The sidewall cargo semi trailer can loads various goods and containers (2 of 20 and/or 1 of 40 feet),since the side wall can be made detachable. The color could be painted as your request, the size and load can be customized according to your requirements. Semi-trailer trucks with railing plate structure design. We have 2/3/4 axles with load capacity of 30/40/60/80/100 tons for your choice. Customizable sidewall height.

We have a wide range of styles

Product Paramenters

2 Axles	3 Axles	4 Axles
Brand: Vehicle Master	Brand: Vehicle Master	Brand: Vehicle Master
Loading Capacity: 30-60T	Loading Capacity: 30-80T	Loading Capacity: 40-100T
Gooseneck Type: Optional	Gooseneck Type: Optional	Gooseneck Type: Optional
Main Beam
Material: Q345/T700	Main Beam Material: Q345/T700	Main Beam Material: Q345/T700
Upper Plate Thickness: 12mm	Upper Plate Thickness: 16mm	Upper Plate Thickness: 18mm
Middle Plate Thickness: 6mm	Middle Plate Thickness: 10mm	Middle Plate Thickness: 12mm
Lower Plate Thickness: 14mm	Lower Plate Thickness: 18mm	Lower Plate Thickness: 20mm
Main Beam Height: 500mm	Main Beam Height: 500mm	Main Beam Height: 500mm
Product Size
L*W: 13000mm*2550mm	L*W: 13000mm*2550mm	L*W: 13000mm*2550mm
Side Wall Height: 600mm-1700mm	Side Wall Height: 600mm-1700mm	Side Wall Height: 600mm-1700mm
Axle
2 Axles *13 Ton VEHICLE MASTER/FUWA/BPW/Other	3 Axles *13/16 Ton VEHICLE MASTER/FUWA/BPW/Other	4 Axles *13/16 Ton VEHICLE MASTER/FUWA/BPW/Other
Tire
12R22.5 (8 Pieces) Linglong/Triangle/Double-Coin/ Bridgestone/Other Brand	12R22.5 (12 Pieces) Linglong/Triangle/Double Coin/ Bridgestone/Other Brand	12R22.5 (16 Pieces) Linglong/Triangle/Double-Coin/ Bridgestone/Other Brand
Rim
9.00*22.5 (8 Pieces) Steel/Aluminum	9.0*22.5 (12 Pieces) Steel/Aluminum	9.00*22.5 (16 Pieces) Steel/Aluminum
Leaf Spring
90mm*13mm*10/90mm*16mm*10Pcs	90mm*13mm*10/90mm*16mm*10Pcs	90mm*13mm*10/90mm*16mm*10Pcs
King Pin
#50(2")/#90(3.5"), JOST/Other Brand	#50(2")/#90(3.5"), JOST/Other Brand	#50(2")/#90(3.5"), JOST/Other Brand
Landing Gear
28 Tons Two Speed JOST/Other Brand	28 Tons Two Speed JOST/Other Brand	28 Tons Two Speed JOST/Other Brand
Vehicle Painting
Electrophoresis painting	Electrophoresis painting	Electrophoresis painting

Key Features:

1. Robust 3-Axle Design:

   • Provides excellent stability and weight distribution, ensuring safe and smooth operation under heavy loads.

2. Durable Side Walls:

   • Fixed or detachable side walls prevent cargo spillage and provide flexibility for transporting different materials.

3. High Load Capacity:

   • Engineered to carry up to 60 tons, accommodating construction materials, agricultural goods, and industrial products.

4. Premium Material Construction:

   • Made from high-strength steel to withstand heavy-duty use and harsh environments.

5. Efficient Suspension System:

   • Equipped with advanced suspension and high-quality axles for superior performance on rough or uneven terrain.

6. Customizable Options:

   • Adjustable side wall heights, optional tarpaulin covers, and additional accessories to suit specific transportation needs.

7. Compliance and Quality Assurance:

   • Certified under ISO 9000 and China’s 3C standards, ensuring top-tier manufacturing quality and operational safety.

Applications:

• Construction Industry: Transporting sand, gravel, bricks, steel rods, and other building materials.
• Agriculture: Hauling crops, grains, fertilizers, and other agricultural goods.
• Industrial Use: Moving bulk commodities like coal, ores, and chemical products.

The 3-Axle Side Wall Truck Trailer offers a perfect combination of strength, adaptability, and efficiency, making it an excellent choice for heavy-duty transportation tasks. Built to perform under demanding conditions, it ensures maximum productivity and long-term reliability for your logistics operations.
