Products Description
|
Basic information
|
|||
|
Announcement model:
|
LZZ1EXVD7LD596232
|
Driving form:
|
8X4
|
|
Wheelbase:
|
1950+3225+1350mm
|
Engine:
|
sinotruk MC11.44-60
|
|
Transmission:
|
HW25712XSL
|
Rear axle speed ratio:
|
4.8
|
|
Body length:
|
9.58 meters
|
Vehicle width:
|
2.55 m
|
|
Body height:
|
3.55 meters
|
Front wheelbase:
|
2022/2022mm
|
|
Rear wheelbase:
|
1860/1860mm
|
Vehicle weight:
|
15.5 tons
|
|
Rated load capacity:
|
15.37 tons
|
Total mass:
|
31 tons
|
|
Tonnage level:
|
Heavy truck
|
Approach angle:
|
17 degrees
|
|
Departure angle:
|
21 degrees
|
Origin:
|
Jinan, Shandong Province
|
|
Segmented markets:
|
Urban construction waste soil
|
Fuel type:
|
diesel oil
|
|
Engine param
|
|||
|
Engine model:
|
MC11.44-50
|
Engine brand:
|
sinotruk Corporation
|
|
Number of cylinders:
|
6-cylinder
|
Fuel type:
|
diesel oil
|
|
Displacement:
|
10.518L
|
Emission standards:
|
National V
|
|
Maximum horsepower:
|
400hp
|
Maximum output power:
|
324kW
|
|
Maximum torque:
|
2100N · m
|
Maximum torque speed:
|
1000-1400rpm
|
|
Rated speed:
|
1900rpm
|
Engine type:
|
High pressure common rail+EGR+SCR
|
|
Container param
|
|||
|
Container length:
|
7.6m
|
Box width:
|
2.35m
|
|
Container height:
|
1.3m
|
Container form:
|
Self dumping type
|
|
Cabin param
|
|||
|
Driver's seat form:
|
Airbag shock absorber seats
|
||
|
Transmission param
|
|||
|
Transmission model:
|
sinotruk HW25712XSL+HW50 flange power take-off
|
Transmission brand:
|
sinotruk Corporation
|
|
Forward gear:
|
12th gear
|
Reverse gears:
|
Two
|
|
tank
|
|||
|
Fuel tank material:
|
aluminium alloy
|
Fuel tank capacity:
|
400L
|
|
Chassis param
|
|||
|
Front axle allowable load:
|
6500/7000kg
|
Rear axle allowable load:
|
17500 (two axis group) kg
|
|
Number of springs:
|
2011/11/12
|
||
|
tyre
|
|||
|
Tire specifications:
|
12.00R20 (reinforced steel ring/mixed pattern)
|
Number of tires:
|
12
|
|
Handling configuration
|
|||
|
ABS anti lock braking:
|
4s/4m
|
||
